Plotting Velocity Against Time
The changing velocity of the sprinter—or of any other moving person or object—can be represented by a velocity-time graph like the one in the Figure below for the sprinter. A velocity-time graph shows how velocity changes over time. The sprinter’s velocity increases for the first 4 seconds of the race, it remains constant for the next 3 seconds, and it decreases during the last 3 seconds after she crosses the finish line.
Acceleration and Slope
In a velocity-time graph, acceleration is represented by the slope, or steepness, of the graph line. If the line slopes upward, like the line between 0 and 4 seconds in the Figure above, velocity is increasing, so acceleration is positive. If the line is horizontal, as it is between 4 and 7 seconds, velocity is constant and acceleration is zero. If the line slopes downward, like the line between 7 and 10 seconds, velocity is decreasing and acceleration is negative. Negative acceleration is called deceleration.
Q: Assume that another sprinter is running the same race. The other runner reaches a top velocity of 9 m/s by 4 seconds after the start of the race. How would the first 4 seconds of the velocity-time graph for this runner be different from the Figure above?
A: The graph line for this runner during seconds 0–4 would be steeper (have a greater slope). This would show that acceleration is greater during this time period for the other sprinter.
Use the following PLIX Interactive to predict what the velocity-time graphs will look like for three baseballs accelerating at different rates:
Interactive Element
Summary
- A velocity-time graph shows changes in velocity of a moving object over time.
- The slope of a velocity-time graph represents acceleration of the moving object.
Review
- Describe a velocity-time graph. What does the slope of the graph line represents?
- In the Figure above, the sprinter reaches a velocity of 2 m/s in just 1 second. At a constant rate of acceleration, how long does it take for her to double this velocity? What is her acceleration during this time period?
- Create a velocity-time graph by plotting the data in the Table below.
| Velocity (m/s) | Time (s) |
|---|---|
| 10 | 1 |
| 30 | 2 |
| 50 | 3 |
| 40 | 4 |
| 40 | 5 |
